Application: Household Appliance Lighting (Range Hood)
FUSION
Loading
Product imageColor Code: WW-NW
Color Designation: White
Beam Angle: 140°
Color Temperature: 2700–6500 K
CRI: >80
SDCM: <7
R9: >0
Luminous Efficacy: 80 ± 10% lm/W
Rated Luminous Flux: 550–650 lm
Working Temperature: −20 to +40 °C
Application: Household Appliance Lighting (Range Hood)
Rated Power Consumption: 7 W
Actual Power Consumption: 7 W ± 10%
Luminous Efficacy: 85 ± 10% lm/W
Input Voltage: 12 VDC
Current: 600 ± 10% mA
Connector: ATX (Customizable according to customer requirements)
Lifetime: 25,000 h
PCB Material: Phenolic
Weight: 100 g
