Automatic Shutdown Mode: Automatic shutdown after 8 hours of operation
FUSION
Loading
Product imageDisplay Type: 7-Segment
Backlight Color of Keys and Display: White
Number and Type of Keys: 4 Touch Keys
Maximum Overlay Glass Thickness: 6 mm
Motor Speed Control: 4 Speeds
Board Supply Voltage: 180–250 V AC
Operating Temperature: 0–85 °C
Motor Type: Single-Phase AC Induction Motor
Light Type: 12 V DC
Accessories: IR Remote Control and External Temperature Sensor
Maximum Remote Control Range: 5 m
Automatic Shutdown Mode: Automatic shutdown after 8 hours of operation
Automatic Motor Speed Control: Motor speed is automatically adjusted according to ambient temperature
Programmable Shutdown Timer
Touch Key Auto-Calibration: Enables automatic calibration of touch keys in different environments
Fully Electronic Operation: Eliminates mechanical motor-starting relays
Switching Power Supply: Enhances efficiency and lighting output current capacity while reducing circuit weight, size, and heat dissipation losses
Lighting Output Current: 300 mA, expandable up to 600 mA
Compatibility: Suitable for all types of 12 V DC lights
Motor Protection: Zero-crossing detection reduces motor stress and helps extend motor lifespan
Short-Circuit Protection: Protects lighting outputs against short circuits
Noise Immunity: Resistant to both high- and low-frequency electrical noise from the mains supply
High-Voltage Test Certification: Capable of obtaining certification for High-Voltage (3 kV) testing
Resistant to Environmental Noise
Automatic Touch Key Calibration
